Description
Features:
1.Swiss brand Raytools laser cutting head ,Germany brand Precitec laser cutting head as optional
2.Imported servo motor and drivers
3.Stability and reliability of light path system and control system.
4.IPG Laser source or Raycus laser source
5.E3015E equipped with exchange table
6.Cypcut operating system
Applicable industry:
High cutting effciency, and the cutting range of metal plate is great. Mainly used for cutting carbon steel, stainless steel,aluminum alloy, titanium alloy,galvanized plate, copper and other metal materials.Widely used in sheet metal processing, electronic chassis, medical equipment,kitchenware, fitness equipment, decoration, advertising, metal processing and other manufacturing and processing industries.
|
Technical parameters |
|
|
Model |
E3015,E4020,E6020 |
|
Cutting size |
3000x1500mm/4000x2000mm/6000*2000mm |
|
Laser power |
1000W 1500W 2000W 3000W 4000W 6000W |
|
Cutting speed |
0-120m/min |
|
Working voltage |
380V/50Hz |
|
Cooling method |
water cooling |
|
Transmission mode |
Dual rack and gear |
|
Repeat positioning accuracy |
±0.02mm |
|
Auxiliary Gas |
Oxygen, Nitrogen, Air |
